Phoenix Contact 1715747 MKDS 1.5/4-5.08 5.08mm Pitch, 4 Way PCB Terminal Strip

- Brand new item, still in OEM packaging

- Check out the images for more product details

Product Details:

Phoenix Contact COMBICON MKDS 5.08mm PCB Terminal Blocks
The MKDS PCB terminal blocks are through hole mount, have a 5.08 mm pitch, rising cage clamp screw terminals and side interlocking.

Features and Benefits:
• Well-known connection principle allows worldwide use
• Low temperature rise, thanks to maximum contact force
• Allows connection of two conductors
• Integrated protective guide prevents incorrect insertion of the conductor underneath the tension sleeve
• Latching on the side enables various numbers of positions to be combined
• RoHS compliant

Note:
Stock number 804-4991 has the postion number stamped on the housing and 883-2921 is bridged internally.

Standards:
Connection in acc. with standard EN-VDE, V0 Flammability rating according to UL 94, DIN EN 60512-5-2:2003-01.

Approvals:
CSA, cRUus, PCT, SEV, CCA,
UL, CSA

UL (E60425); CSA (LR13631)

Specifications:
Number of Contacts: 4
Pitch: 5.08mm
Number of Rows: 1
Mounting Type: Through Hole
Termination Method: Screw
Type: PCB Terminal Block
Current Rating: 22A
Body Orientation: Straight
Colour: Green
Voltage Rating: 250 V
Series: MKDS 1.5/4-5.08
Material: Polyamide

Manufacturer: Phoenix Contact

Manufacturer Part Number: 1715747

Shipping Dimensions: 2X2X1 CM

Shipping Weight: 6 GRAMS
