Eaton FAZ-C20/2-NA DIN Rail Mount Circuit Breaker, 20A, 2 Pole 240VAC - New
- Brand new item, still in OEM packaging
- - Check out the images for more product details
Product details:
Optimum product quality, tested reliability and safety stand for best protection of personnel, installations and plant. Eaton’s FAZ-NA DIN rail mountable circuit breaker is designed for use in branch service applications. The FAZ-NA Series is available with B, C and D characteristics in accordance with UL 489, CSA C22.2 No.5, UL 1077, CSA C22.2 No.235 and IEC 60947-2. These devices are CE marked.
Broad Range of Tripping Curves:
- B Characteristic for Standard Circuit Protection
- - C Characteristic for Higher Inrush Currents
- - D Characteristic for Inductive and Capacitive Loads
- Features:
- - Rated Currents Up to 40A
- - DIN Rail Mount
- - Suitable for Branch Circuit Device Protection
- - Current Limiting Design
- - Fulfill UL489, CSA C22.2 No. 5 and IEC 60947-2
- - Optional Ring Tongue Connection
- - Module Width of Only 17.7 mm Per Pole
- - Reliable and Safe Operation
- - Captive Screws Cannot Be Lost
- - Snap-On Accessories
- - Contact Position Indicator
- - Finger Proof
- - Trip-Free Mechanism
- Applications:
- - Convenience Receptacle Circuits
- - Motor Control Circuits
- - Load Circuits Leaving the Equipment
- - HACR Internal/External Equipment
- - PLC I/O Points
- - Computers
- - Power Supplies
- - Control Instrumentation
- - Relays
- - UPS
- - Power Conditioners
Manufacturer: Eaton
Manufacturer Part Number: FAZ-C20/2-NA
Product Range: FAZ Series
Voltage Rating VAC: 240VAC
Voltage Rating V DC: 48V
Current Rating: 20A
No. of Poles: 2 Pole
Circuit Breaker Mounting: DIN Rail
