ABB EF19-1.0 / 1SAX121001R1102 Overload Relay 1NO + 1NC, 0.3 → 1 A F.L.C, 1 A Contact Rating, 54 W, 3P, AF Range
Electronic Overload Relay
PRODUCT DETAILS:
Electronic overload relays are the alternative to the thermal overload relays; they offer reliable and fast protection for motors in the event of overload or phase failure.
Overload protection – trip class 10E, 20E, 30E selectable
Phase loss sensitivity
Adjustable current setting for overload protection
Automatic or manual reset selectable
Trip-free mechanism
Status indication
STOP and TEST function
Sealable operating elements
Attribute
Value
FLC Motor Rating
0.3 → 1 A
Contact Current Rating
1 A
Range
AF Range
Pole Configuration
3P
Series
EF19
Mounting Style
Direct Contactor
Power Rating
54 W
Normal State Configuration
NO/NC
Reset Method
Automatic, Manual
Terminal Type
Screw
Number Of Auxiliary Contacts
2
Width
44.4mm
Depth
59.3mm
Length
85mm
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
+70°C
Operating Temperature Range
-25 → +70 °C
Contact Voltage Rating
690 V ac/dc
MANUFACTURER: ABB
PART NUMBER: EF19-1.0 / 1SAX121001R1102
WEIGHT: 184 GRAMS
DIMENSIONS: 9 X 7 X 5 CM
