Phoenix Contact TRIO POWER Switched Mode DIN Rail Power Supply, Part No.2866268

Write a review

$198.00

Spend $150.00 to Free Shipping

Free Shipping

Spend $150.00 to Free Shipping

Phoenix Contact TRIO POWER Switched Mode DIN Rail Power Supply Part No. 2866268 Brand Phoenix Contact Series TRIO POWER Type Switched Mode Electrical Phase 1 AC or DC Input Voltage ac Number of Outputs 1 Input Voltage 85 → 264V...View more

Hurry Up! Only 5 Left in Stock!

Add to cart Out of stock

I agree with the terms and conditions

This item is a recurring or deferred purchase. By continuing, I agree to the cancellation policy and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted.

Add to compare Added to compare Add to wishlist Added to wishlist

Sku: LHTIGH-2866268

Barcode: 4046356046626

Product type:

Availability: Many in stock Unavailable

Description
Reviews ( 0 )

Phoenix Contact TRIO POWER

Switched Mode DIN Rail Power Supply

Part No. 2866268

Brand	Phoenix Contact
	Series	TRIO POWER
	Type	Switched Mode
	Electrical Phase	1
	AC or DC Input Voltage	ac
	Number of Outputs	1
	Input Voltage	85 → 264V ac
	AC or DC Output Voltage	dc
	Output Voltage	24V dc
	Output Current	2.5A
	Dimensions	115 x 32 x 130mm
	Width	32mm
	Depth	130mm
	Height	130mm
	Load Regulation	±1%
	Model	TRIO-PS/1AC/24DC/ 2.5
	Mounting Type	DIN Rail Mount
	Maximum Temperature	+70°C
	MTBF	500000h
	Minimum Temperature	-25°C
	Efficiency	86%
	Ripple And Noise	30mV Pk-Pk

Features & Benefits

. IP20-rated for safe handling and protection against objects larger than 12mm
• IEC Class I protection means you can trust it’s safely earthed to prevent shocks
• Operating temperature range of -25°C to +70°C makes it compatible with harsh settings
• Easily starts high-load applications thanks to a dynamic power reserve of 150% of the nominal current for 5s
• Push-in connections are easy and tool-free
